FT-5740 BLDC Brushless DC Motor Customized For Robotic Lawn Mower

Model Number : FT-5740 BLDC

Brand Name : FUTENG

Place of Origin : China

Certification : CE/ROHS/FCC/REACH/ISO14001/ ISO9001/ISO45001/IATF16949

MOQ : 1000 Pieces

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 8000 0000

Delivery Time : 15-30 days/Negotiable

Packaging Details : Standard Export Carton & Customzied

Name : BLDC Brushless DC Motor

Continuous Current(A) : 5-6.8A, 5-6.8A

Efficiency : IE 4

Speed(RPM) : 3000-5000rpm, 3000 -4000rpm

Commutation : Brushless, Brushless

Construction : Permanent Magnet, Permanent Magnet

Frame : 60mm

Motor Mounting Type : Flange Mount

Protect Feature : Explosion-Proof, Explosion-proof

Rated Power : 100 W

Rated voltage : 12-48v

Speed Rpm : 3 000 RPM

Torque : 0.1-0.8NM, 0.1-0.44N.m

Type : Brushless Motor, Brushless Motor

Usage : Boat, Car, Electric Bicycle, Cosmetic Instrument, Home Appliance, Fan, Smart Home, BOAT, Car, Electric Bicycle, FAN, Cosmetic instrument, SMART HOME

Warranty : 3 months ~ 1 year

Shaft diameter : 8mm Customzied

Contact Now

Product Description

Customized FT-5740 BLDC Brushless DC Motor for Robotic Lawn Mower

item

value

Warranty

1year

Place of Origin

China

Dongguan

Brand Name

Futeng Motor

Model Number

FT-57BL

Usage

BOAT, Car, Electric Bicycle, FAN, Cosmetic instrument, SMART HOME

Type

Brushless Motor

Torque

0.1-0.44N.m

Construction

Permanent Magnet

Commutation

Brushless

Protect Feature

Explosion-proof

Speed(RPM)

3000 -4000rpm

Continuous Current(A)

5-6.8A

Efficiency

IE 4

Product name

5740 Brushless Dc motor

Rated speed

3000-4000rpm

Rated torque

0.1-0.44N.m

Number of poles

4

motor length

107mm

Voltage

24-48VDC

Insulation Class

B

Shaft diameter

8mm Customzied

Rated Current

5-6.8A

Certification

CE, ROHS

Product Series

Poles No.

Rated Voltage

Rated Speed

Rated Torque

Rated Power

Motor Length

42mm BLDC Motor

8

24v

4000rpm

0.0625~0.25N.m

26~105w

41~100mm

57mm BLDC Motor

4

36v

4000rpm

0.055~0.44N.m

23~184w

37~107mm

60mm BLDC Motor

8

48v

3000rpm

0.3~1.2N.m

94~377w

78~120mm

80mm BLDC Motor

4

48v

3000rpm

0.35~1.4N.m

110~440w

78~138mm

86mm BLDC Motor

8

48v

3000rpm

0.35~2.1N.m

110~660w

71~138.5mm

110mm BLDC Motor

8

310v

3000rpm

1.65~6.6N.m

518~2073w

83~173mm

130mm BLDC Motor

10

310v

3000rpm

2.39~11.94N.m

750~2500w

115~190mm

FT-5740 BLDC Brushless DC Motor Customized For Robotic Lawn Mower

FT-5740 BLDC Brushless DC Motor Customized For Robotic Lawn Mower

Packaging & Shipping

Can be customized & Standard Export Carton

FT-5740 BLDC Brushless DC Motor Customized For Robotic Lawn Mower

FAQ

1. Can you make the gearbox or gearmotor with custom specifications?

YES. We have strong R&D capability, also a great term of engineers, each of them have many work years experience.

2. Do you provide the samples?

YES. Our company can provide the samples to you

3.Do you provide technology support?

YES. Our company have strong R&D capability, we can provide technology support if you need.

4. why should you buy from us not from other suppliers?

Professional one-to-one motor customized . The world's large enterprise of choice for high quality suppliers . ISO9001:2008 quality management system certification, through the CE, ROHS certification.

5. How to ship to us?

We will ship the samples to you according to the DHL or UPS or FEDEX etc account you provide.

6. How can I know the product is suitable for me?

Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.
